SIGLENT Technologies presents a new series of spectrum analyzers. The new models combine the performance and reliability of the highly successful SSA3000X series with the features and ease of use of the SVA1000X series. The result is a spectrum analyzer with the PLUS of performance and flexibility.
The instruments are available with bandwidths from 9 kHz to 2.1 GHz respectively 3.2 GHz. With the smallest resolution bandwidth (RBW) of 1 Hz, a noise level of -161dBm can be displayed. Together with the amplitude accuracy of <0.7dB, even the smallest signals just above the noise of the device can be detected and measured.
The option "advanced measurements" (SSA3000X plus-AMK) has also been extended with two additional measurements. In addition to the previous measurements of channel power (CP), adjacent channel power (ACPR), occupied bandwidth (OBW), TOI and waterfall diagram (monitor), the harmonic and carrier-to-noise ratio (CNR) measurements are now also implemented. The available EMC option offers EMI filter bandwidths of 200Hz, 9kHz, 120kHz and 1MHz as well as the quasi-peak detector defined in CISPR.
In addition to the improvements and additions to the well-known functions, a completely new function has been added to the SSA3000X-plus. So, now there is a vector signal analysis option for analog and digital modulations (SSA3000X plus-AMA/DMA) available. This can be used, for example, to measure the error vector magnitude (EVM) of PSK, MSK or QAM modulated signals. The 10.1-inch touch screen, the possibility to connect an external mouse & keyboard and the integrated web server make the operation easy and comfortable.
The starting price for the SSA3000X plus series is 1469 € plus VAT.
- on Test & Measurement
Siglent Technologies further expands its range of spectrum analyzers
September 16, 2019 | 15:40
After the recently introduced Spectrum & Vector Network Analyzer SVA1032X, Siglent is now launching another Spectrum Analyzer series. The SSA3000X-plus is available in bandwidths of 2.1GHz and 3.2GHz. The main differences to the existing SSA3000X series are improved specifications, expanded functionality and the 10.1-inch touch screen.
