Siglent: new generation Super Phosphor Oscilloscope

May 11, 2017 | 00:00
The SDS1000X-E employs a 256-level intensity grading display function and a colour temperature display mode not found in other models in this class. Image: Siglent
The SDS1000X-E employs a 256-level intensity grading display function and a colour temperature display mode not found in other models in this class. Image: Siglent
Siglent's SDS1000X-E Series employs a new generation of SPO (Super Phosphor Oscilloscope) technology that provides a new perspective on signal fidelity and performance. The system noise is also lower than similar products in the industry.

The SDS1000X-E Super Phosphor Oscilloscope is available in one bandwidth, 200 MHz. It has a maximum sample rate of 1 GSa/s and a standard record length of 14 Mpts. It comes with a minimum vertical input range of 500 uV/div, an innovative digital trigger system with high sensitivity and low jitter, and a waveform capture rate of 100,000 frames/sec (normal mode) and 400,000 frames/sec (sequence mode).

The SDS1000X-E also employs a 256-level intensity grading display function and a colour temperature display mode not found in other models in this class. The oscilloscope supports multiple powerful triggering modes including serial bus triggering. Decoding is standard configuration, including IIC, SPI, UART, CAN, LIN.

History waveform recording and sequential triggering enable extended waveform recording and analysis. Another addition is the new 1 million points FFT math function that gives the SDS1000X-E very high frequency resolution when observing signal spectra.

The net price of the SDS1000X-E is €359.

For more information, visit www.siglenteu.com
