Looking for practical tools to enhance your electronics design and prototyping endeavors? Elektor’s May/June 2025 edition features innovative test and measurement projects, including a crystal tester, a milliohmmeter adapter, the PbMonitor battery monitor, and more. Enjoy the magazine!
Since 1961, Elektor has showcased vital test and measurement tools that support electronics design, prototyping, debugging, and validation. Over the years, we’ve covered oscilloscopes, multimeters, signal and function generators, power supplies, electronic loads, and LCR meters. In the May/June 2025 edition of ElektorMag, we continue this tradition with innovative projects like the PbMonitor battery monitor, a B-field integration magnetometer, a stand-alone crystal tester, a milliohmmeter adapter, a low-cost I2C tester, and more. Enjoy the magazine!
Elektor May/June 2025
Inside the Elektor May/June 2025
Whether you’re starting a new test and measurement project or simply looking for insightful reading, the May/June 2025 edition is packed with value. It features a diverse selection of background articles, innovative test and measurement projects, and industry insights to sharpen your skills and keep you current with the latest tools and techniques. It’s an essential resource for electronics engineers, makers, and anyone passionate about precise measurement and electronics design.
Table of contents
PbMonitor v1.0: A Battery-Monitoring System for UPS and Energy Storage Applications
Solar Charge Controller with MPPT (1): Basic Principles of a Solar Controller for Stand-Alone Systems
B-Field Integration Magnetometer: With Home-Made Sensors
Milliohmmeter Adapter: Uses the Precision of Your Multimeter
PbMonitor system connected to the 48-V battery bank for real-time monitoring.
Frequency Counter: Portable and Auto-Calibrating Via GPS
Stand-Alone Crystal Tester: How Accurate Is Your Clock Source?
Low-Cost I2C Tester: Connect I2C Devices Directly to Your PC
Raspberry Pi Stand-Alone MIDI Synthesizer (2): Enhancing Our Setup with Intelligence
An FPGA-Based Audio Player with Equalizer (2): Adding Volume Control, Advanced Mixing, and a Web Interface
Stand-Alone Crystal Tester
Precise or Accurate?: Your Instruments Need to Be Both!
AD7124: A Precision ADC in Practice: Features for Sensor Signal Conditioning
PID Control Tool: Optimize Your Parameters Easily
Nortonized Wien Bridge Oscillator: Small Changes Yield Significant Improvements
Putting a $0.10 Controller to the Test: The CH32V003 RISC-V Microcontroller and
From Life’s Experience: Who Doesn’t Honor the Small Things?
2025: An AI Odyssey: The Transformative Impact on Software Development
More Test and Measurement Content
Elektor is an essential resource for DIY electronics projects and design tips related to test and measurement solutions. Elektor Gold and Green Members can immerse themselves into these topics! Our members receive full access to our online library, and they enjoy benefits including a 10% discount on many products in the Store.
