Elektor.TV | Beep the sounding logic probe

March 3, 2015 | 23:53
Get the kit and build your own Beep, it’s a piece of cake!
Get the kit and build your own Beep, it’s a piece of cake!
“Beep” is a simple circuit to make logic signals audible without having to look away from the pin under test. Even if you have an upmarket logic analyzer and are completely at ease with its operation, you are unlikely to use it to debug simple circuits like Arduino and Raspberry Pi add-on boards. That’s where “Beep” comes in.



Read the full article here, it's free for everyone!
