16-bit Data Logger

An ADC module for Arduino, Elektor Linux Boards and more

16-bit Data Logger
To make accurate voltages measurements you need an A/D converter (ADC) chip which has good resolution. The folks at Elektor Labs have developed a board containing a four-channel 16-bit ADC. It’s no coincidence the board uses a Gnublin/EEC connector which makes it compatible with the Elektor’s Linux board, Xmega Webserver and the new Extension shield for Arduino. A universal C library is included to make integration a walk in the park.
Downloading of this magazine article is reserved for registered users only.
Login | Register now!
Relevant websites
Gerber file

CAM/CAD data for the PCB referred to in this article is available as a Gerber file. Elektor GREEN and GOLD members can exclusively download these files for free as part of their membership. Gerber files allow a PCB to be produced on an appropriate device available locally, or through an online PCB manufacturing service.

Elektor recommends its business partner Eurocircuits as the company of choice for its own prototypes and volume production in selected cases.

Download the BOM list
The BOM (Bill of Materials) is the technically exhaustive listing of parts and other hardware items used to produce the working and tested prototype of any Elektor Labs project. The BOM file contains deeper information than the Component List published for the same project in Elektor Magazine. If required the BOM gets updated directly by our lab engineers. As a reader, you can download the list here.
Want to learn more about our BOM list? Read the BOM list article for extra information.
Component List
Resistors (0.1W, 0603)
R1,R2 = 100kOhm 1%
R3,R4 = 120kOhm 1%
R5 = 270kOhm 1%
R6,R7 = 2.2kOhm 1%
R8 = 1kOhm 5%
R9,R10 = 560Ohm 1%
Capacitors (0603)
C1 = 47pF 5%, 50V, C0G/NP0
C2 = 10µF 20%, 6.3V, X5R
C3 = 470nF 10%, 10V, X5R
C4,C5 = 100nF, 10% 16V, X7R
D1 = LED, yellow, 0805
D2 = LED, green, 0805
T1 = 2N7002 (SMD SOT23)
K1,K2 = 3-way PCB screw terminal block, 0.2’’ pitch
K3 = 14-pin (2x7) pinheader, 0.1’’ pitch
JP1 = 3-pin pinheader, 0.1’’ pitch, with jumper
JP2,JP3 = 2- pin pinheader, 0.1’’ pitch, with jumper
JP4 = 8-pin (2x4) pinheader, 0.1’’ pitch, with jumper
PCB 130485-1
