Latest comments
HaSch
HaSch 2 hours ago
The level shifter around BSS138 is not working for me, Neopixel LEDs remains dark. Are there different BSs138 types in the market? Maybe it will work with another brand of BSS138 or another MOSFET. What other actions could bring the circuit to life?
ESP8266 web server for Neopixel LED strips [160487]
ClemensValens
ClemensValens 1 day ago
Are you aware of the fact that the kind of pushbuttons shown in the photograph is typically rated for only 50 mA @ 24 V? In your circuit it has to pass the full (inrush) current to the Arduino, so you might want to choose a more suitable type. I modified the circuit to move the switch out of the power path, see V5 (attached). I added an LED too.
On/Off Button for Arduino; switching off software controlled
ClemensValens
ClemensValens 1 day ago
Looking once more at V3 I think an extra diode is needed to prevent voltage inversion passing through the body diode of Q1. See D1 in attached V4.
On/Off Button for Arduino; switching off software controlled
Sarbjit Singh Mal
Sarbjit Singh Mal 2 days ago
As per the circuit description,  voltage across Capacitor C15 will never go above VBE(sat)  i.e. Base to Emitter saturation voltage ( 1.0V) of transistors T7 & T8 (when Base to Emitter  diode will get forward bias) in case of positive  DC offset voltage more than  0.55 V ( for T8) or a negative DC offset greater than 0.85 V (for T7) at the output and almost entire offset voltage (less  1.0V VBE(sat)  of T7/T8) will appear across R23 (15kΩ) and current through R23 will be limited to approx. 3.67 mA { i.e. (56-1.0)/15000} in case of DC offset voltage swing to even up to +V or –V supply rail. Capacitor C15 is already shown as non-polar in the circuit schematic. Mal
Q-Watt - Simple Audio Power Amplifier (110656)
Stacy Markel
Stacy Markel 2 days ago
LAN monitoring lets you keep track of your entire local network, including your workstations, routers, switches, servers, and printers PRTG monitors your LAN and sends notifications about connection problems, limited availability, or overloaded server. The functionality works in every browser and is secured. Visit  Firefox Support Number for more information
WebServer for Wide Area and Local Area Control & Monitoring
