Who's Afraid of Phased Locked Loops?
Analog System Lab Kit PRO is a 14-step learning-by-experimenting program in analog electronics. It provides students with a solid and engaging framework. All experiments are based on general purpose integrated circuits. Main topics are: amplifiers, feedback, multivibrators. Integrators, differentiators, analogue filters, function generators, V-C oscillators, Phase Lock Loop (PLL), Automatic Gain Control, Automatic Volume Control, DC-DC Converter, (LDO) regulator Digitally Controlled Gain Stage Amplifier, Digitally Programmable Square and Triangular wave generator/oscillator.
